activating concorde’s droop nose
Concorde's droop nose was designed to give pilots better visibility during takeoff and landing. The droop nose of Concorde Alpha Foxtrot has not operated since the aircraft was decommissioned and the hydraulic fluid drained, following its final flight in November 2003.
To celebrate Concorde50, our conservation team and volunteers have been working on an exciting project and were successful and got it moving again on 9th April 2019: the 50th anniversary of the first British Concorde flight, followed by the first public move on Saturday 13th April.
We would like to thank all of the volunteers who have so generously given their time to this project, as well as Zeus Hydratech who generously provided the motor and pump unit and Exxon Mobil, who have kindly donated the vital M2V hydraulic oil.
Concorde G-BOAF Filton 26 Nov 03 (Credit: BAE Systems)
Making it happen
To make this special project a reality, we need to establish a method of energising the hydraulic system for the droop nose without affecting any other systems on the aircraft. We also need to activate some of the original aircraft electrical system to be able to select the nose up and down.
To do this, we have laid new cables under the aircraft floor to supply a transformer, which will take the voltage to 28volts. This is compatible with the aircraft, allowing us to use the original aircraft selectors.
The next issue to overcome is to supply 3000psi of hydraulic pressure to the droop nose system. Zeus Hydratech have kindly agreed to supply us with a bespoke motor and pump unit (power pack).
To effect simple connectivity to the existing hydraulic circuit, it was decided the power pack would be installed inside the Concorde nose wheel bay.
our progress so far…
